Waterproof Ultrasonic Module JSN-SR04T Distance Transducer Sensor

Waterproof Ultrasonic Module JSN-SR04T Distance Transducer Sensor

₹ 0.00
₹ 0.00
Sale Sold out
Shipping calculated at checkout.
  • Safe Secure Delivery
  • 10 Days Returnable
  • Secure Payment Transaction

Out of stock
  • For bulk orders or B2B inquiries, email us: support@uglandindia.com
  • Bulk order on WhatsApp

Specification:

Parameter Details
Model JSN-SR04T
Operating Voltage 5V DC
Operating Current ~30 mA
Measuring Range 20 cm to 600 cm (0.2 m to 6 m)
Accuracy ±1 cm
Sensor Type Ultrasonic Transducer
Output Digital (PWM pulse duration)
Working Frequency 40 kHz (ultrasonic)
Interface 4-pin: VCC, Trig, Echo, GND
Waterproof Rating Sensor head: IP66/IP67 equivalent
Operating Temperature -20°C to +70°C
Board Size ~41 mm × 28.5 mm
Cable Length ~2.5 meters (sensor to board)



Features:

  • Waterproof Transducer
    Durable and sealed sensor head allows for reliable use in rain, moisture, or submerged environments.

  • Long Range Measurement
    Measures distances from 20 cm to 600 cm (0.2 m to 6 m) with high accuracy.

  • Digital Trigger/Echo Interface
    Easy to connect with microcontrollers using standard Trigger and Echo pins.

  • Pre-Calibrated Output
    Outputs distance via pulse width, easily converted to cm in code.

  • Compact Design with Separate Transducer
    Sensor module and transducer are separated for flexible mounting.

Description:

Long-Range, Weatherproof Ultrasonic Transducer for & Microcontrollers

The JSN-SR04T Waterproof Ultrasonic Module is a high-performance, weather-resistant distance measurement sensor that uses ultrasonic waves to detect obstacles and measure range. Unlike standard ultrasonic modules, this sensor features a fully waterproof transducer, making it ideal for outdoor, wet, or harsh environments such as robotics, liquid level sensing, parking systems, and smart trash bins.

It operates with high accuracy and stability over long ranges and communicates via standard digital I/O (trigger and echo) compatible with ESP32, Pi, and other platforms.
