TDS Water Conductivity Sensor Module, 0~1000ppm Water Quality Monitoring TDS Meter Board

TDS Water Conductivity Sensor Module, 0~1000ppm Water Quality Monitoring TDS Meter Board

₹ 0.00
₹ 0.00
Sale Sold out
Shipping calculated at checkout.
  • Safe Secure Delivery
  • 10 Days Returnable
  • Secure Payment Transaction

Out of stock
  • For bulk orders or B2B inquiries, email us: support@uglandindia.com
  • Bulk order on WhatsApp

Specification:

Parameter Details
TDS Measurement Range 0 – 1000 ppm
Output Voltage 0 – 2.3V (typical range for analog output)
Operating Voltage 3.3V – 5.5V DC
Current Consumption < 20 mA
Output Type Analog Voltage (linear with TDS)
Interface Pins 3-pin: VCC, GND, AOUT
Sensor Type Waterproof Conductivity Electrode
Sensor Material Stainless Steel Probe (water-safe)
Temperature Range 0°C – 40°C (non-compensated)
Response Time < 500ms
PCB Dimensions ~28mm × 20mm
Cable Length Typically 50–100cm (varies by model)



Features:

  • TDS Measurement Range: 0–1000 ppm
    Suitable for fresh water, drinking water, and low-conductivity liquids.

  • Analog Voltage Output:
    Provides a linear analog signal that increases with rising TDS level. Connects easily to analog pins.

  • High-Precision Conductivity Probe:
    Measures ion concentration in water and converts it to readable electrical data.

  • Safe and Isolated Design:
    Probe and circuitry are electrically isolated for safety and reliability during immersion.

  • Waterproof Sensor Probe:
    Durable stainless steel sensor tip allows submersion in water without damage or shorting.

  • 3-Pin Signal Output Interface:
    Simple GND, VCC (3.3–5V), and analog output pin (AOUT) for plug-and-play integration.

  • Wide Compatibility:
    Works with ESP8266, ESP32, STM32, Pi (with ADC) and more.

Description:

Accurate Water Quality Monitoring Module for ESP, and Other Microcontrollers.

The TDS Water Conductivity Sensor Module is a compact and highly sensitive Total Dissolved Solids (TDS) meter designed for monitoring the purity and quality of water. This module is capable of measuring TDS levels from 0 to 1000 ppm (parts per million) and is widely used in water filtration systems, aquariums, hydroponics, agriculture, and environmental monitoring.

It detects ionic content in water (such as salts, minerals, and metals) by measuring the electrical conductivity, which directly correlates to the TDS value. The analog voltage output of the sensor can be easily read using ESP32, or any ADC-compatible microcontroller.
