Linear Magnetic Hall Sensor

Linear Magnetic Hall Sensor

₹ 0.00
₹ 0.00
Sale Sold out
Shipping calculated at checkout.
  • Safe Secure Delivery
  • 10 Days Returnable
  • Secure Payment Transaction

Out of stock
  • For bulk orders or B2B inquiries, email us: support@uglandindia.com
  • Bulk order on WhatsApp

Description:

The Hall Effect Sensor Module is designed to detect the proximity of a magnet and is compact in size. When the magnetic field exceeds a specified threshold, the open-collector output transistor activates, pulling the logic-compatible output low and illuminating the onboard LED indicator.

This sensor is fast and operates within a turn-on threshold of 35-450 Gauss, with a minimum hysteresis of 20 Gauss. It functions within a voltage range of 4.5 to 24 volts and uses the Allegro Microsystems A3144EUA sensor. The module features a 3-pin interface: signal, V+, and GND.

To use the sensor, connect a 10K pull-up resistor between the “S” pin and the V+ pin, and attach the GND pin to ground. When a magnet is brought close, the “S” pin will go low (pulled to ground), turning on the onboard LED indicator.

The sensor detects the magnetic field and outputs an analog voltage value. You can adjust the sensitivity of the sensor using a potentiometer.

Pins:

  1. VCC ↔ 2.3V ~ 5.3V
  2. GND ↔ power supply ground
  3. AOUT ↔ MCU.IO (analog output)
  4. DOUT ↔ MCU.IO (digital output)

Application:

  1. Motor speed measurement
  2. Object position detection
  3. Smart car
  4. Electronic bricks

Freatures:

Features wide range voltage comparator LM393

Adjustable sensitivity

Signal output indicator with the retaining bolt hole, convenient installation

Output form digital switch output (0 and 1 high and low level)

Signal output indication

Single channel signal output

The output effective signal is low level

When there is sound, outputs low level and the signal light

Can be used for Acoustic control light, give sound and light alarm working with the Photosensitive sensor, and sound control, sound detect.

Specification:

Specifications:
Operating Voltage (VDC): 3.3 ~ 5
Length (mm): 35
Width (mm): 15
Height (mm): 14
Weight (g): 3
