DJI 2212 920KV Brushless DC Motor for Drone with Black Cap (CW Motor Rotation)

DJI 2212 920KV Brushless DC Motor for Drone with Black Cap (CW Motor Rotation)

₹ 0.00
₹ 0.00
Sale Sold out
Shipping calculated at checkout.
  • Safe Secure Delivery
  • 10 Days Returnable
  • Secure Payment Transaction

Out of stock
  • For bulk orders or B2B inquiries, email us: support@uglandindia.com
  • Bulk order on WhatsApp

Specification:

Specification Details
Model DJI 2212 (CW Rotation) with Black Cap
KV Rating 920KV (RPM per volt)
Rotation Direction Clockwise (CW – Black Cap)
Motor Type Brushless Outrunner
Stator Size 22mm (diameter) × 12mm (height)
Shaft Diameter ~3.17mm
Mounting Hole Spacing Standard 16x19mm (M3 screw compatible)
Operating Voltage 7.4V – 14.8V (2S–4S LiPo)
Max Current ~12–15A (depending on propeller & voltage)
Max Power Output 180W – 220W
Efficiency High – optimized winding and magnet alignment
Motor Weight ~55g (without propeller)
Connector Type 3.5mm gold-plated bullet connectors (pre-soldered)
Recommended Propellers 8x4.5, 9x4.7, 10x4.5 (based on voltage and thrust need)



Festures:

  • KV Rating: 920KV
    Optimized for stability and lift in medium-sized drones using 3S–4S LiPo batteries.

  • Clockwise (CW) Rotation
    Black cap identifies motor direction—meant to be paired with counterclockwise (CCW) red cap motor.

  • Durable Construction
    CNC aluminum casing and hardened steel shaft ensure mechanical durability under dynamic loads.

  • Pre-Soldered 3.5mm Bullet Connectors
    Easy plug-and-play connectivity with ESCs (Electronic Speed Controllers).

  • High Torque-to-Weight Ratio
    Ideal for lifting cameras or payloads in aerial photography drones.

  • Compatible with 2-Blade and 3-Blade Propellers
    Supports prop sizes like 9450, 1045, 8045, etc., with prop adapter thread on top.

  • Efficient Cooling Fins
    Keeps motor temperature low during extended flights.

Description:

High-Efficiency Drone Propulsion Motor for Multirotor Applications

The DJI 2212 920KV Brushless DC Motor with Black Cap (Clockwise Rotation) is a high-performance, lightweight, and reliable motor specifically designed for use in quadcopter and multirotor drone platforms. Featuring a KV rating of 920, this motor strikes a perfect balance between torque and speed, making it ideal for aerial photography drones, FPV racers, and DIY UAV projects.

Built with premium quality neodymium magnets, copper windings, and CNC-machined aluminum housing, the 2212 motor delivers smooth, vibration-free rotation, improved heat dissipation, and long operational life.
