Arduino UNO 3.5 inch TFT Touch Screen LCD Module
Arduino UNO 3.5 inch TFT Touch Screen LCD Module
Regular price
₹ 0.00
Regular price
Sale price
₹ 0.00
Unit price
per
Shipping calculated at checkout.
- Safe Secure Delivery
- 10 Days Returnable
- Secure Payment Transaction
Out of stock
Couldn't load pickup availability
For bulk orders or B2B inquiries, email us: support@uglandindia.com
Bulk order on WhatsApp
| Parameter | Specification |
|---|---|
| Display Size | 3.5 inches (diagonal) |
| Resolution | 480 × 320 pixels |
| Display Type | TFT LCD (Thin Film Transistor Liquid Crystal Display) |
| Touch Type | Resistive Touchscreen |
| Touch Controller | XPT2046 or similar |
| Color Depth | 65K or 262K colors (16-bit color) |
| Backlight | LED (built-in) |
| Controller IC | ILI9486 / ILI9488 (varies by version) |
| Interface Type | Parallel 8-bit (via UNO digital pins D0–D7) |
| Compatible Boards | Arduino UNO, Mega 2560 (with adjustment), etc. |
| Operating Voltage | 5V (direct plug-in to Arduino UNO) |
| Touchscreen Interface | SPI (via separate pins) |
| Power Consumption | Approx. 60–100mA (depending on brightness and usage) |
| Pin Configuration | 18-pin interface directly compatible with UNO’s female headers |
| Dimensions | Approx. 85mm × 55mm × 5mm |
| Mounting | Direct plug-and-play on Arduino UNO |
Description:
This small 3.5-inch touch screen display module is designed especially for Arduino UNO. This is ideal for DIY anywhere, anytime, and does not require any separate power source or case to hold it. The screen also comes with a stylus to interact with the small screen.
Note: Product color may differ from the picture shown here.
Features of 3.5 inch TFT LCD Touch Screen Display Shield for Arduino Uno:
- Resistive touch screen TFT LCD, 3.5inch, 480x320 resolution.
- Standard Arduino interface, compatible with development boards like Arduino UNO, Leonardo, UNO PLUS, NUCLEO, XNUCLEO.
- Onboard stand-alone touch controller, better touching than solutions that use AD pins directly for touch control.
- PWM backlight control allows adjusting the backlight to a comfortable level.
- Micro SD slot, provides an easy way to store photos for displaying.
- Controlled via SPI, only a few Arduino pins are used.
- Comes with STM32 and Arduino examples, convenient for porting.
Key Parameters of 3.5 inch TFT LCD Touch Screen Display Shield for Arduino Uno:
- LCD Type: TFT
- LCD Interface: SPI
- LCD Controller: ILI9486
- Touch Screen Type: Resistive
- Touch Screen Controller: XPT2046
- Colors: RGB, 65K colors
- Resolution: 480x320 (Pixel)
- Aspect Ratio: 8:5
- I/O Voltage: 3.3V/5V
