18650 Battery In-Series Lithium Cell Holder Open Case with Wire

18650 Battery In-Series Lithium Cell Holder Open Case with Wire

₹ 0.00
₹ 0.00
Sale Sold out
Shipping calculated at checkout.
  • Safe Secure Delivery
  • 10 Days Returnable
  • Secure Payment Transaction

Out of stock
  • For bulk orders or B2B inquiries, email us: support@uglandindia.com
  • Bulk order on WhatsApp

Specification:

Parameter Specification
Supported Cell Type 18650 Li-ion (18mm x 65mm cylindrical cells)
Configuration Series (2S / 3S / 4S / etc., depending on model)
Output Voltage (2S) 7.4V nominal (8.4V fully charged)
Output Voltage (3S) 11.1V nominal (12.6V fully charged)
Material ABS / Nylon Plastic + Metal Spring/Flat Contacts
Contact Type Nickel-plated steel spring and/or flat plate
Wire Type 24AWG–20AWG flexible insulated copper wires
Wire Length Typically ~10–15 cm (depends on manufacturer)
Operating Temperature -20°C to +60°C
Mounting Options Screw holes or adhesive (varies by model)



Features:

  • Supports In-Series Configuration:
    Connects two or more 18650 cells in series, increasing the output voltage (e.g., 7.4V for 2S, 11.1V for 3S).

  • Pre-Soldered Wire Leads:
    Equipped with red (+) and black (−) silicone-insulated wires for easy connection to circuits or BMS boards.

  • Open-Frame Design:
    Provides good ventilation, easy access for inspection or replacement, and lightweight construction.

  • Secure Snap-Fit Design:
    Each cell is firmly held in place using spring contacts and plastic end restraints for stable electrical contact.

  • Durable ABS or Nylon Plastic:
    Made from flame-retardant, impact-resistant plastic, ensuring mechanical safety and long service life.

  • Compact and Modular:
    Easily stackable or mountable in enclosures or chassis, ideal for compact designs.

Description:

The 18650 Battery In-Series Lithium Cell Holder (Open Case with Wire) is a modular plastic enclosure designed to hold and connect two or more 18650 lithium-ion cells in series configuration. It features pre-attached wires for quick integration, an open-frame design for airflow and accessibility, and a snap-fit or clip-based structure for secure cell retention.

This holder is ideal for building custom battery packs, DIY projects, portable electronics, or any application requiring a safe and structured housing for cylindrical lithium cells.
